JMG MC85 – FULLY ELECTRIC PICK & CARRY CRANE | 8.500 KG CAPACITY Valid Inspection Compact dimensions, powerful lifting performance and excellent manoeuvrability. The JMG MC85 combines a maximum lifting capacity of 8.500 kg with fully electric drive, making it ideal for industrial lifting, machinery installation and work in confined spaces. Manufacturer: JMG Cranes Model: MC85 Manuf. Year: 2024 Type: Fully electric Pick & Carry crane Maximum lifting capacity: 8.500 kg Total machine weight: 9.990 kg Maximum lifting height: approx. 10 m Maximum horizontal reach: approx. 6 m DIMENSIONS Length: 3.655 mm Width: 1.700 mm Height: 1.900 mm DRIVE & STEERING Drive: Front-wheel drive with counter-rotation Traction motors: 2 × 7.5 kW AC, 72 V Steering: Rear-wheel steering Steering angle: ?90° to +90° / 180° total BATTERY & HYDRAULICS Battery voltage: 72 V Battery capacity: 620 Ah Operating time: 8 working hours, as stated by the manufacturer Hydraulic pump motor: 1 × 16 kW AC, 72 V TYRES Front: 2 × superelastic 355 × 65/15" Rear: 2 × superelastic 7.50/15" BRAKING & SAFETY Hydraulic foot-operated service brakes on all wheels Hydraulic parking brake on the front wheels, applied automatically or by button Electronic safe load indicator Overturning moment limiter - Hydraulic winch - Angle-adjustable manual jib with manual extension 6 & 4.5 T - Non-marking tyres - Radio remote control - Hydraulic forks - 11tons Hookblock KEY FEATURES & BENEFITS - Fully electric operation – zero exhaust emissions during use, ideal for indoor applications. - Maximum lifting capacity of 8.500 kg. - Pick & Carry capability for lifting and moving loads, subject to the applicable load chart. - Compact dimensions: just 1.700 mm wide and 1.900 mm high. - Excellent manoeuvrability thanks to 180° rear steering and counter-rotating front drive wheels. - Hydraulically telescoping boom with proportional control for precise load positioning. - Two independent AC traction motors, each rated at 7.5 kW. - 72 V / 620 Ah battery, with a manufacturer-stated operating time of 8 working hours, depending on use and battery condition. - Electronic load monitoring and overturning moment limitation. - Solid superelastic tyres. - Robust chassis manufactured from formed and welded steel plate. CE (Declaration of Conformity). More detailed pictures / product movie on our website. pfeifermachinery.com Above specifications are subject to change without prior notice and subject to errors.
